Scan2Fix4Aspx product

Fonctionalities

• analysis of HTML pages HTML produced by the Web server (development, staging, production)
• scan based on a url list, or by autodiscover starting with a root url
• autodetection of invalid Url (href, src) within the pages
• quality analysis of HTML pages according to the W3C and WCAG repositories
• analysis if css files (duplication of attributs, validity of referenced URL)
• cross reference HTML / CSS
• loading time measurement and graph
• HTTP status, cross references of URL

Getting started

• Maven et Sonar are enough
• start in command mode / task scheduler or kron is recommended
• auto upgrade of the rule engine (maven download)
• integration with existing process via the configuration POM.XML file
• the scan speed is configurable in Staging mode (intense scan without pause) or Production by default (2 secondes between each http request)
• the autodiscover is configurable for an automatic crawler of site

Integration in development and production environments

• Sonar provides a multi views dashboard :
• continous integration (jenkins for ex)
• source code + unit test (Sonar and Scan2Fix 4CSharp or 4Php or 4VB6 or 4Java)
• production supervision (IIS logs Scan2Fix4Iis, Windows Stack trace Scan2Fix4Stt)
• web site qualityaudit (Scan2Fix4Aspx)
• Sonar Web Server is accessible for all technical actors (developers, project managers, Web integrators, production)
• Generation of static Html reports : standalone and publishable

Quick and simple installation

• during the command process, provide the sonar server hostname
• install a java jre
• install maven 2 or 3
• install Sonar (any version)
• copy the plugin (the dwnload link is provided during the commande process) in SONAR_HOME/extensions/plugins
• restart the Sonar server
• under admin / Profiles, activate all the rules in the profile "Default Aspx Profile")
• start a scan Asp/Html and the violations appera in the Sonar dashboard)

Example of pom.xml file

<project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/maven-v4_0_0.xsd">

• <modelVersion>4.0.0</modelVersion>
• <groupId>com.qualitesys.wsqualitychecker</groupId>
• <artifactId>tfs_MEL_2012_06_19_aspx</artifactId>
• <version>2012_06_19_01</version>
• <name>tfs_MEL_2012_06_19_aspx</name>

• <properties>
• <sonar.language>aspx</sonar.language>
• <sonar.httpautodiscover>yes</sonar.httpautodiscover>
• <!-- _dp_ is for ":" or "deux points", "_sl_" is for "/" or "slash" -->

• <sonar.httpseed>http_dp__sl__sl_www.mysite.com_sl_; http_dp__sl__sl_www.mysiteelse.com_sl_</sonar.httpseed>
• <sonar.httpenvironment>production</sonar.httpenvironment>

• <sonar.reporting06sites>mysite.com;mysiteelse.com</sonar.reporting06sites>
• </properties>

• <pluginRepositories>
• <pluginRepository>
• <id>QualityChecker remote repository</id>
• <url>http://www.qualitesys.com/mavenrepository/</url>
• </pluginRepository>
• </pluginRepositories>

• <build>
• <!-- COMPULSORY -->
• <sourceDirectory>C:your_dir_to_source_code</sourceDirectory>
• <plugins>
• <plugin>
• <groupId>com.qualitesys.maven.plugins</groupId>
• <artifactId>qcr-maven-plugin</artifactId>
• <executions>
• <execution>
• <id>PhaseCleanGoalqcrgoalclean</id>
• <phase>clean</phase>
• <goals>
• <goal>qcrgoalclean</goal>
• </goals>
• </execution>
• <execution>
• <id>PhaseHttpScanGoalqcrhttpscan</id>
• <phase>generate-sources</phase>
• <goals>
• <goal>qcrgoalhttpscan</goal>
• </goals>
• </execution>

• <execution>
• <id>PhaseCompileGoalqcrgoalcompile</id>
• <phase>compile</phase>
• <goals>
• <goal>qcrgoalcompile</goal>
• </goals>
• </execution>
• </executions>
• </plugin>
• <plugin>
• <groupId>org.apache.maven.plugins</groupId>
• <artifactId>maven-site-plugin</artifactId>
• <version>3.0-beta-3</version>
• <configuration>
• <reportPlugins>
• <plugin>
• <groupId>org.apache.maven.plugins</groupId>
• <artifactId>maven-project-info-reports-plugin</artifactId>
• <version>2.2</version>
• </plugin>
• <plugin>
• <groupId>com.qualitesys.maven.plugins</groupId>
• <artifactId>qcr-maven-plugin</artifactId>
• </plugin>
• </reportPlugins>
• </configuration>
• </plugin>
• </plugins>
• </build>

</project>

Example with Maven only

Nota : the plugin for Sonar is not required. Usage is limited to 5 days.

mvn clean compile site

Maven will generate the static Web site under target/site/index.html

Example with Maven and Sonar

Nota : the plugin for Sonar is not required. It is provided at the validation step of the command process or on explicit request (contact@qualitesys.com).

mvn clean compile sonar:sonar

To check the URL validity (type status!= 200) :

mvn clean compile qcr:qcrgoalreporting06 sonar:sonar

Violations dictionary
